Slitting Line Tooling


Thickness tolerance +/-0.001 Flatness 0.002 Parallelism 0.002

Processing Material

Carbon steel, Stainless steel, High-strength steel, Aluminium, Copper

Regarding to high-precision requirements , We now can ensure that the thickness tolerance to +/-0.001mm .Therefore ,to inner circle ,its tolerance can be achieved to H13 .All inspections of high precision knife are made in the constant temperature room

All of our slitter knife , Spacers , are 6 times heat treatment

With the increasing requirements on the precision of sheet metal processing , We have developed ultra-high-precision cutting tools ,only the precision milling tools can match with its accuracy so far +/-0.001mm thickness tolerance and Ra0.1U surface roughness are our common standards .By using our technique and expertise ,We can meet customers high tolerance requirements in regard to thickness, parallelism ,flatness and so on

Slitter-Knife-(1)

Slitter Knife (2)

Material Selection of Blade


Type of material to be cut Thickness of material to be cut
<0.6mm <1.5mm <3.0mm <6.0mm >6.0mm
Cold -rolled material LS11 LS53 LS 51 LS11  LS53 LS11 LS53 LS7 LS7 LS6 LS13 LS7 LS 13
Hot-rolled  material LS7  LS 6 LS7 LS6 LS13 LS7 LS 13
Electricla steel Oriented LS7  LS5
Unoriented LS51 LS5 LS42
Stainless steel LS7 LS5 LS53 LS7  LS53 LS7 LS6 LS7 LS6 LS13 LS7 LS13
Copper Aluminum Foil tape LS7 LS11 LS51 LS11 LS5 LS53 LS11 LS53 LS7 LS13 LS53 LS7 LS7 LS13
Hardened strip TCT LS23 LS42 LS51 LS5 LS53 LS51

Seperator Discs

Rubber Spacers (4)

Rubber Spacers (5)

Rubber Spacers (6)

Rubber Spacers (7)

Rubber Spacers (8)

Rubber Spacers (12)

pro (2)

pro (3)

pro (4)

Slitter Knife (17)

Slitter Knife (16)

Slitter Knife (18)
